NETUM 80mm Thermal Receipt Printer, WiFi POS Printer with Auto Cutter, USB Serial Ethernet LAN Port Support Cash Drawer ESC/POS
-
Nick
> 24 hourWiFi printing was confusing.. got it working.. -Get the driver from the NETUM website -Do the connection to the printers wifi first -Do the setup there for it to connect to your regular wifi network in STA settings, assign static IP -Connect back to your regular WiFi network -Ping the printer IP and check it is there -Run the driver package, for the connection set as other, not USB -Add as Standard TCP/IP and the static IP you set on the printer -That will fail to detect it, dont worry -Set as Generic Network Card -Leave as RAW, Port 9100 -And surprise, it finally works!! Youre welcome ;-)
-
Joe Bagodonuts
> 24 hourPrinter works fine, but the WiFi setup is squirrely, especially if you dont have a Windows computer. The instructions appear to be missing the beginning steps. Heres how I got it working: Press Status Switch on back of printer. The printer will print out some information. Look under [AP Info] on printout. Mine included: WiFi Printer / 012345678 Connect to the wireless network WiFi Printer (password 012345678). Change your WiFi adapter to the same subnet as the printer. E.g. if printer IP is 10.10.100.254 (displayed in the printout), set your IP to 10.10.100.200. Open a browser, browse to 10.10.100.254. User/password is admin/admin. From this point on, follow the prompts from the instructions included with the printer or on the Amazon product page.
-
Kevin Chen
> 24 hourIt’s so hard to connect to your computer and set it up. I even called 2 friends who use printers a lot and wasn’t able to set it up for me. I spent 3 hours trying to set these up. I don’t recommend this to anyone. I rather by this point just buy a Bluetooth portable printer.
- NT-806 is an 80MM thermal receipt cashier POS printer. It comes with USB+Wifi interfaces to meet different demands. Besides, it has sound and light indicators, so don"t need to worry about missing order again in a noisy environment. We have so many customers from all over the world. Customers are highly recommended about its stable and clearly printing, they said " Their working efficiency has been increased 65% by means of this excellent printer.
- Last but not least, we have more details about the installation and setup on the manual and selling page below, so please don"t worry about operation. Our only pursuit is making your business EASY!
Main features:
Support all Windows software based on ESC/POS command
This printer support all Windows and Linux system. Do not Support Mac PC System iPad,iPhone. Driver download link: gzxlscan.com/downloads/.Support Wireless connection.Do not work with Square.
High efficiency with auto cutter
NT-806 have a 3 inch thermal receipt printer with auto cutter and the fastest printing speed--300 mm/sec.
Beeping Sound Can be closed.
You can turn on/down/off the sound volume by DIP Switch below machine.
Product Specification
- Print Method：Direct Thermal
- Print Speed：300mm/s
- Resolution：576dots/line or 572dots/line
- Printing Width：72mm
- Paper separator(option)：48mm/52mm/56mm/58mm/64mm/68mm/76mm/80mm
- Interface：USB+WIFI
- Input:AC 100V-240V 50/60HZ
- Output:DC 24V/2.5A
WIFI IP Address Setting.
|
|
|
|
|
|---|---|---|---|
Step 11, Connect the printer with PC and switch on the printer. 2, Find the wireless network and link it. Then find the file named“ HF-LPB100” and link it – after successful connection , go to next step. 3, Enter the IP address ( 10.10.100.254 ) into the PC browser, press Enter we can see as below: |
Step 2Enter “ admin” for the user name and default password is also “admin”. Press ok and then Next: Select “AP+STA mode” , and save. Note: When the module is selected to STA mode (NIC), then re-start the module, you can not reuse the wireless configuration, SSID number can not be found. 4, Select “ STA Setting ” as below; |
Step 3Select “ STA Setting ” as below; |
Step 4Then click “Scan”, it will appear selection as below: Above are all your current wireless network, select one of your wireless device available to be used, then click “ OK ” |
WIFI IP Address Setting
|
|
|
|
|
|---|---|---|---|
Step 5Input the correct configuration within the dialog, as below:. STA setting is complete, click "save". |
Step 6Select "Other Setting", setting as below: After finish the setting, click “ Save”. |
Step 7Restart the module, as below: Module configuration is complete |
Step 8Click computer “Start” “ Run”, Input word “CMD”，as below： Input “ping 192.168.1.105 -t” If details shows as below , means connection is Ok Return to the driver -" properties " - " port "-" add port ", consistent with the add ports |
|
|
|
|
|
|---|---|---|---|---|
| NT-806 | NT-306 | NT-1809DD | 2 1/4"" x 50 rolls | |
| Print Method | Direct Thermal | Direct Thermal | Direct Thermal | |
| Print Speed | 300mm/s | 260mm/s | 160mm/s | |
| Printing Width | 72mm | 72mm | 56mm | |
| Paper separator(option) | 48mm/52mm/56mm/64mm/68mm/76mm/80mm | 48mm/52mm/56mm/64mm/68mm/76mm/80mm | 48mm/52mm/56mm | |
| Connection | USB+WIFI | USB | Bluetooth+USB | |
| Device Supported | Windows | Windows | Windows,Mac,Smart Phone | |
| Barcode | 1D & QR Code | 1D & QR Code | 1D & QR Code |
